• Overview

    Depending on the purity grade, the following can be checked:

    • head diameter
    • head height
    • thread length
    • thread formed yes / no
    • external thread diameter and core diameter
    • thread pitch
    • partial thread length
    • drive formed yes / no
    • width across flats for hexagon drives
    • width across corners
    • head cracks
    • other sortable features
